SR60V Solvent Reclaim System
15 Gallon / 60 Liter Class I, Division I Solvent Recycler with Vacuum Assist
Industrial Solvent Recovery for Higher Throughput Applications
The SR60V Solvent Reclaim System is a 15-gallon (60-liter) batch-type solvent distillation unit engineered for safe, efficient on-site solvent recycling in industrial environments. Designed for facilities with moderate to high solvent usage, the SR60V combines a robust thermal-oil heated distillation vessel with a pneumatic venturi vacuum system to lower boiling temperatures, improve safety, and expand solvent compatibility.
Certified for Class I, Division I, Group D hazardous locations, the SR60V is ideal for reclaiming flammable and combustible solvents while reducing disposal costs, solvent purchases, and environmental impact.
Key Features
-
15-gallon / 60-liter working capacity
-
Batch-type solvent distillation
-
Electrically heated thermal oil jacket
-
Vacuum-assisted distillation (SR60V)
-
PLC-controlled automatic operation
-
Explosion-proof electrical components
-
Automatic cool-down cycle for safer residue removal
-
Designed for continuous industrial use
SR60V Vacuum-Assist Advantage
The pneumatic venturi vacuum system lowers the boiling point of solvents, allowing recovery at reduced temperatures. This improves safety, reduces thermal stress on solvents, and enables recovery of higher-boiling and heat-sensitive solvents.
Compressed air requirements:
-
90–120 PSI
-
Clean, dry, oil-free air
-
Up to 15 CFM peak demand
Standard Construction & Materials
-
Jacketed distillation vessel
-
Powder-coated steel frame
-
304 stainless steel wetted parts
-
Air-cooled condenser with ¼ HP motor
-
Self-contained heating system for simplified installation
Automation & Controls
-
PLC microprocessor control with operator interface
-
Automatic batch operation
-
Self-diagnostic fault monitoring
-
RTD temperature sensors monitoring:
-
Thermal oil
-
Sludge
-
Reclaimed solvent
-
-
High-level float switch protection
-
Programmable operating parameters
-
Automatic 1-hour cool-down mode
Safety & Certifications
-
Class I, Division I, Group D certified
-
Certified to UL 2208
-
CSA & UL approved electrical components
-
Explosion-proof heaters, motors, and controls
-
Designed for environments with flammable solvent vapors under normal operation
Electrical & Utility Requirements
Electrical
-
208/240V
-
Single phase
-
50/60 Hz
-
24 amps
Compressed Air (Required)
-
90–120 PSI
-
Clean, dry, oil-free
-
15 CFM peak usage
System Dimensions
-
Approximate footprint: 36” D × 36” W × 75” H
-
Indoor installation required
Typical Applications
-
Industrial parts cleaning
-
Paint and coatings operations
-
Manufacturing & MRO facilities
-
Printing and graphics
-
Machine shops and fabrication
-
Solvent-based cleaning processes
Available Options
-
Stainless steel condenser upgrade
-
Automatic solvent fill system
-
Overfill protection for vacuum tank
-
Nitrocellulose protection system
-
External light tower status indicator
-
Plastic liner bags (2 mil or 3 mil)
-
High-temperature distillation kits
-
Quick oil cooling system
-
Sludge removal baskets and crane systems
-
Start-up and spare parts kits
Options are configured based on solvent type and application requirements.
| Feature | SR30V | SR60V |
|---|---|---|
| Working Capacity | 8 gallons / 30 liters | 15 gallons / 60 liters |
| Process Type | Batch solvent distillation | Batch solvent distillation |
| Heating System | Thermal oil, electric | Thermal oil, electric |
| Heating Power | 5 kW explosion-proof heaters | 5 kW explosion-proof heaters |
| Vacuum System | Pneumatic venturi | Pneumatic venturi |
| Certification | Class I, Div I, Group D | Class I, Div I, Group D |
| Condenser | Air-cooled | Air-cooled |
| Controls | PLC automation | PLC automation |
| Cool-Down Cycle | Automatic | Automatic (1 hour) |
| Best For | Light–moderate solvent use | Moderate–higher solvent throughput |
Both SR30V and SR60V systems are configured based on solvent type, safety requirements, and throughput needs.
Why Choose an SR Series Solvent Recycler?
-
Reduces solvent purchasing costs
-
Minimizes hazardous waste disposal
-
Improves workplace safety
-
Designed for Class I, Division I environments
-
Fully automated batch operation
-
Configurable for a wide range of industrial solvents
-
Backed by North American safety certifications
Frequently Asked Questions
What is the SR60V solvent recycler?
The SR60V is a 15-gallon (60-liter) batch solvent distillation system designed for on-site solvent recovery in industrial environments. It includes PLC automation, thermal-oil heating, and Class I, Division I, Group D certification.
What does the “V” in SR60V mean?
“V” indicates the pneumatic venturi vacuum system is included. Vacuum assist lowers boiling temperature and supports safer recovery of higher-boiling or heat-sensitive solvents.
Is the SR60V explosion-proof?
The SR60V is certified for Class I, Division I, Group D environments (UL 2208) using explosion-proof rated components for hazardous locations.
What utilities are required?
Electrical: 208/240V, single phase, 50/60 Hz, 24 amps.
Air: 90–120 PSI clean, dry, oil-free air; up to 15 CFM peak.
What’s the working capacity?
15 gallons / 60 liters working volume.
How does the system heat the solvent?
It uses electrically heated thermal oil circulating through a jacketed vessel for controlled, efficient heat transfer.
What happens when a batch finishes?
The unit automatically enters a cool-down mode (about 1 hour) to allow safer residue removal at reduced temperature.
What options are available?
Options include auto-fill, overfill protection for the vacuum tank, stainless condenser upgrades, external light tower, nitrocellulose protection system, liner bags, and start-up/spare parts kits.
Request a Quote
Each SR60V Solvent Reclaim System is configured based on solvent type, safety requirements, and throughput needs.
Contact SolventRS to discuss your application and available options.
