Description
Most glove box-style parts washers are aqueous-only — atomizing solvent inside an enclosed cabinet is considered too dangerous for standard electrical components. The Kresco SWC™ Series breaks that rule safely. Built entirely of stainless steel and fitted with Class I Division 1 explosion-proof components (lighting, impeller and control panel), the SWC Series solvent version lets you spray-clean parts with solvent inside a sealed, enclosed cabinet — something most glove box washers on the market simply can’t do.
Engineered for Hazardous-Location Solvent Cleaning
- Class I Div. 1 explosion-proof components throughout, including the LED lighting system, solvent fume extraction impeller, and control panel — rated for hazardous locations where atomized solvent vapor is present
- 1/2 HP motorized solvent fume extraction continuously evacuates hazardous vapors from the cabinet during operation
- Door safety interlock switch automatically interrupts the cleaning cycle the instant a door is opened
- All-stainless-steel cabinet and recirculating tank construction, built to hold up against solvent exposure
- Sealed cabinet design with glove ports keeps solvent and fumes contained — operator cleans through built-in nitrile/neoprene/butadyl gloves while watching through a large Lexan view window with replaceable shields
The result: OSHA, NFPA and cQPSus code-compliant solvent spray cleaning in a footprint and workflow that, until now, has mostly been reserved for aqueous glove box washers.
Common Applications
- Degreasing and cleaning parts, tools and machinery components
- Surface cleaning of manufactured parts prior to coating or painting
- Restoring engines and mechanical parts of vehicles
- Maintenance of aircraft components
- Cleaning mining and wastewater pumps for rebuild
- Cleaning flexo/litho printing plates and components
Key Features
- Recirculating Tank — stainless-steel tank on wheels, available in 15, 20, 30 and 45-gallon fluid capacity
- Pump-Powered Process — choice of low-pressure and high-pressure pumps for the cleaning tool
- Flow Regulator — regulates fluid flow through cleaning tools
- Ergonomic Controls — valves and cleaning tool controls mounted on the front leg for easy access
- Large View Window — Lexan window with easily replaceable shields
- Inline filtration traps circulating debris so cleaning fluid can be reused cycle after cycle
Standard Equipment
- Protective gloves (nitrile, neoprene or butadyl)
- Flow-thru brush and spray gun with a wide array of available spray patterns (splash, multiple streams, flat, hollow cone, full cone, square)
- Air blow gun
- Perforated UHMW polyethylene work shelf — 500 lb standard load capacity (higher capacities available on request)
Choice of Fluid Pumps
| Pump Type | Working Pressure |
|---|---|
| High-Pressure Pneumatic Pump | 100 to 3,000 PSI |
| Low-Pressure Diaphragm Pump | 30 to 100 PSI |
Optional Features
- Front Guillotine Door — pneumatic front-opening door provides complete access to the work surface and enables features like a retractable shelf
- Rotating Table — increases operator productivity and reduces stress from manipulating parts
- Retractable Shelf — retractable, tiltable shelf for more ergonomic loading and unloading
- Window Clean-Off Nozzles — air-knife technology keeps the view window clear for better visibility inside the cabinet
Available Sizes & Interior Dimensions
| Model | Interior Dimension (L x W x H) | Door Opening (DW x DH) |
|---|---|---|
| SWC2836 | 28″ x 36″ x 35″ | 16″ x 34-5/8″ |
| SWC3636 | 36″ x 36″ x 35″ | 24″ x 34-5/8″ |
| SWC3648 | 36″ x 48″ x 35″ | 24″ x 34-5/8″ |
| SWC3660 | 36″ x 60″ x 35″ | 24″ x 34-5/8″ |
| SWC3672 | 36″ x 72″ x 35″ | 24″ x 34-5/8″ |
| SWC4848 | 48″ x 48″ x 35″ | 36″ x 34-5/8″ |
| SWC4860 | 48″ x 60″ x 35″ | 36″ x 34-5/8″ |
| SWC4872 | 48″ x 72″ x 35″ | 36″ x 34-5/8″ |
| SWC6060 | 60″ x 60″ x 35″ | 48″ x 43-1/4″ |
| SWC6072 | 60″ x 72″ x 35″ | 48″ x 43-1/4″ |
| SWC7272 | 72″ x 72″ x 35″ | 58″ x 38″ |
Delivery dimensions and suggested floor layouts are available upon request. Custom-sized tanks and fluid transfer mechanisms can also be configured to your application.
Specifications
| Air Inlet | ID: 1/2″ / 20 CFM @ 80 PSI |
| Electrical Requirements | 1/2 HP / 120V / 60Hz / 1 Ph |
| Loading Capacity | Standard: 500 lb (other capacities available on request) |
| Warranty | 2 Years |
Code Compliance
Kresco parts washer cabinets and their pre-engineered features are approved and compliant to code for industrial and commercial use in both Canada and the United States. The solvent version’s electrical components comply with Class I Div. 1 Hazardous Locations Standards. Compliant with OSHA and NFPA guidelines, and cQPSus Certified.
Why Choose Solvent Recycling Systems
Running a solvent-based cabinet washer means managing spent solvent. Pair your SWC Series cabinet with one of our batch solvent recyclers to reclaim and reuse mineral spirits or other cleaning solvent on-site instead of paying for disposal and fresh solvent. Freshly cleaned bare metal parts are also vulnerable to flash rust — ask us about pairing this washer with Cortec VCI corrosion protection to keep parts rust-free between cleaning and their next process step.
Documentation & Downloads
Download the Kresco SWC Series Parts Washer Cabinet Brochure (PDF)
Have a specific part size, throughput, or hazardous-location requirement? Contact us and we’ll help you spec the right SWC configuration.
