Description
The Kresco PowerBlast™ Series is a line of heavy-duty industrial sandblast cabinets built for production shops that blast all day: eleven pre-engineered sizes from 28″ × 36″ up to 72″ × 72″ working dimensions, 12-gauge welded steel construction, a tunable cyclonic media separator, a self-cleaning cartridge dust collector, and your choice of suction or pressure delivery. Every cabinet is built to order in Kresco’s shop in Quebec, Canada, and backed by a two-year industrial warranty. Solvent Recycling Systems supplies, installs and services PowerBlast cabinets across the Midwest and ships nationwide.
Need a number? Request a quote or call (847) 833-7010 with your largest part size, the abrasive you plan to run and your compressor’s CFM.
Suction or Pressure: Which PowerBlast Do You Need?
The cabinet is the same; what changes is how the abrasive gets to the nozzle.
- Suction (siphon) cabinets pull media from the hopper with an air jet in the gun. Lower air demand, simpler to run, ideal for glass bead, aluminum oxide and plastic media on cleaning, deburring and finishing work. A 3/8″ nozzle with a 3/16″ air jet draws about 48 CFM at 80 PSI.
- Pressure cabinets add a 1.5 cu ft pressure pot under the cyclone that pushes media through the hose at line pressure. Much faster on heavy scale, rust and coatings, and the usual choice when you run steel grit or shot. A 3/8″ nozzle at 80 PSI needs about 161 CFM, so check your compressor first.
If you are not sure, tell us what you are removing and how many parts per shift; we size the delivery system, nozzle and dust collector together.
Standard Specifications
| Item | Standard | Optional |
|---|---|---|
| Delivery system | Suction or pressure | — |
| Media capacity | 1.5 cu ft storage hopper (1.5 cu ft pressure pot on pressure models) | — |
| Metal thickness | 12 gauge, bolted and welded panels | Heavier gauge on request |
| Floor capacity | 500 lb | 1,000 to 5,000 lb |
| Gloves | Leather sleeve, rubber gauntlet | Wide-opening / ergonomic inserts |
| Nozzle | Boron carbide, 5/16″ ID | 1/4″, 3/8″, 7/16″ |
| Blast gun control | Foot pedal | No-contact pedal |
| Window | Lexan view window | — |
| Lighting | 24″ high-efficiency LED fixture | — |
| Air blow gun | Included | — |
| Media regulation valve | Included | — |
| Doors | Dual large-opening product doors with seal-tight hinges | Door safety switch, door safety lock |
| Warranty | Two-year industrial warranty on cabinet and dust collector | — |
Eleven Pre-Engineered Sizes (Custom to 72″ × 72″)
All PowerBlast cabinets are 75″ tall overall with a 35″ interior height. Choose by the largest part you need to turn inside the cabinet and by the door opening you need to load it.
| Model | Interior (L × W × H) | Door opening (W × H) | Overall footprint (L × W) |
|---|---|---|---|
| PB2836 | 28″ × 36″ × 35″ | 16″ × 34-5/8″ | 28½” × 42¼” |
| PB2848 | 28″ × 48″ × 35″ | 16″ × 34-5/8″ | 28½” × 54¼” |
| PB3636 | 36″ × 36″ × 35″ | 24″ × 34-5/8″ | 36½” × 42¼” |
| PB3648 | 36″ × 48″ × 35″ | 24″ × 34-5/8″ | 36½” × 54¼” |
| PB3660 | 36″ × 60″ × 35″ | 24″ × 34-5/8″ | 36½” × 66¼” |
| PB3672 | 36″ × 72″ × 35″ | 36″ × 34-5/8″ | 36½” × 78¼” |
| PB4848 | 48″ × 48″ × 35″ | 36″ × 34-5/8″ | 48½” × 54¼” |
| PB4860 | 48″ × 60″ × 35″ | 36″ × 34-5/8″ | 48½” × 66¼” |
| PB4872 | 48″ × 72″ × 35″ | 36″ × 34-5/8″ | 48½” × 78¼” |
| PB6060 | 60″ × 60″ × 35″ | 48″ × 43-1/4″ | 60½” × 66¼” |
| PB6072 | 60″ × 72″ × 35″ | 48″ × 43-1/4″ | 60½” × 78¼” |
| PB7272 | 72″ × 72″ × 35″ | 58″ × 38″ | 72½” × 78¼” |
Dimensions from the Kresco PowerBlast user manual (July 2026). Shipping dimensions and suggested floor layouts are available on request.
Media Recovery: Tunable Cyclonic Separator
Every PowerBlast cabinet ships with a stand-alone cyclonic separator that uses centrifugal force to pull dust, paint chips, rust and broken-down fines out of the airstream and return good abrasive to the storage hopper. An adjustable air inlet lets you tune it to the media you run, from light glass bead to steel grit, angular or spherical, in any mesh size. A large debris trap drawer catches the junk. The separator is sized to the dust collector:
| Separator | RB13 | RB16 | RB24 | RB30 |
|---|---|---|---|---|
| Body diameter | 13″ | 16″ | 24″ | 30″ |
| Air flow | 600 CFM | 900 CFM | 1,200 CFM | 1,800 CFM |
| Overall (L × W × H) | 22″ × 22″ × 78″ | 22″ × 22″ × 84½” | 22″ × 22″ × 101″ | 22″ × 22″ × 106″ |
| Inlet ID | 4″ / 5″ | 5″ / 6″ | 6″ / 7″ | 7″ / 8″ |
| Outlet ID | 6″ | 7″ | 8″ | 8″ |
| Storage hopper | 1.5 cu ft | |||
Dust Collection: Self-Cleaning Cartridge Collectors
PowerBlast cabinets are ventilated by a Kresco CDC cartridge dust collector with automatic pulse cleaning, a dust drum on a trolley and an optional fan muffler that keeps noise under 80 dB. Collector size follows cabinet size and how dirty the parts are:
| Collector | CDC600 | CDC900 | CDC1200 | CDC1800 |
|---|---|---|---|---|
| Motor | 1 HP | 2 HP | 3 HP | 5 HP |
| Fan | 600 CFM | 900 CFM | 1,200 CFM | 1,800 CFM |
| Filter cartridges | 2 | 2 | 4 | 4 |
| Filter area | 636 sq ft | 636 sq ft | 1,272 sq ft | 1,272 sq ft |
| Overall (L × W × H) | 48″ × 23″ × 114″ | 48″ × 23″ × 120″ | 48″ × 45″ × 124″ | 48″ × 45″ × 124″ |
| Shipping height* | 84″ | 90″ | 94″ | 94″ |
| Fan muffler | Under 80 dB | |||
*Adjustable legs assembled on site. Full collector specs, filter part numbers and the NFPA conversation for aluminum and combustible dust are on our Kresco CDC cabinet dust collector page.
Ergonomic Options for Long Shifts
Kresco designed the PowerBlast around operators who blast for hours, not minutes. Standard on every cabinet: foot-controlled blast gun, ergonomic-height controls, two product loading doors and a large view window. Add-ons:
- No-contact foot pedal
- Work turntable (rubber-lined available)
- Exterior rail and cart for heavy parts
- Rotary basket with gun support for batches of small parts
- Large-opening glove inserts and arm rests
- Elevating work platform
- Chain block slot for overhead loading
Multi work station cabinets
Because the PowerBlast is modular, Kresco also builds it as a multi work station cabinet: one enclosure with more than one operator station, so two people can blast at the same time when a single cabinet has become the bottleneck. Tell us your part flow and we’ll send the multi work station brochure and a layout.
Construction Options and Code Compliance
- Rubber lining — 1/8″ heavy-duty rubber sheet on cabinet walls, the cyclonic separator and the work turntable extends equipment life when running aggressive media.
- Door safety switch — interrupts blasting the moment a door opens.
- Door safety lock — keeps doors locked for a set time after blasting stops so dust settles before the operator opens up.
- Code compliant — Kresco cabinets and their pre-engineered features are approved for industrial and commercial use in both Canada and the United States.
Blast Guns, Nozzles and Wear Parts
We stock the consumables that keep a PowerBlast running:
- G5 suction gun (standard on suction cabinets) and SH5 (aluminum or steel body) with ceramic, tungsten carbide or boron carbide nozzles in 1/4″, 5/16″, 3/8″ and 7/16″, paired with 1/8″ to 7/32″ air jets.
- G15 heavy-duty suction gun with 3/4″ nozzle adaptor and repair kit.
- Cabinet gloves — 30″ leather-sleeve gloves (GLO-VIN-8 / GLO-VIN-10 for 8″ and 10″ ports), 40-mil natural rubber gauntlet, fleece lined, EN388 abrasion level 4. Vinyl/Naugahyde-sleeve versions for CleanBlast cabinets.
- Lexan window protectors, cartridge filters, media regulation valves and pop-up plungers for pressure models.
Order parts through our parts desk with your cabinet serial number.
Compressed Air: Plan Before You Buy
The number-one reason a new cabinet disappoints is a compressor that can’t keep up. Kresco’s working figures at the nozzle:
| Nozzle ID | Suction gun @ 80 PSI (with matching air jet) | Pressure @ 60 PSI | Pressure @ 80 PSI | Pressure @ 100 PSI |
|---|---|---|---|---|
| 1/4″ | 21 CFM | 55 CFM | 68 CFM | 81 CFM |
| 5/16″ | 34 CFM | 88 CFM | 113 CFM | 137 CFM |
| 3/8″ | 48 CFM | 126 CFM | 161 CFM | 196 CFM |
| 7/16″ | 65 CFM | 170 CFM | 217 CFM | 254 CFM |
| 1/2″ | 85 CFM | 224 CFM | 280 CFM | 338 CFM |
From the Kresco PowerBlast air consumption tables. Nozzles wear and their ID grows, so leave headroom; Kresco recommends 100 PSI at the nozzle for fast, high-volume cleaning. Our blast media chart covers which abrasive to run for each job.
Where PowerBlast Cabinets Earn Their Keep
Machine shops and job shops prepping weldments for paint, powder coaters removing scale before coating, firearms and aerospace component finishing with glass bead or aluminum oxide, foundries cleaning castings, and maintenance departments stripping parts for rebuild. Blasted steel starts flash-rusting within hours, so most of our cabinet customers also run a Cortec VpCI rust preventative step right after the cabinet.
Related Kresco Equipment
- CleanBlast Series — compact suction cabinets for light-industrial and automotive work (4 sizes to 48″ × 48″).
- ECO420 — entry-level glass bead cabinet for small shops.
- Wet blast cabinet — slurry blasting for dust-free, bright finishes.
- Blast rooms — for parts larger than 72″ × 72″.
- CDC cartridge dust collectors and SBP pressure blast pots.
Pricing and Lead Time
PowerBlast cabinets are built to order and priced by size, delivery system, dust collector and options. Send us your largest part dimensions, abrasive, parts per shift and compressor rating and we will return a configured quote with lead time. Request a PowerBlast quote or call (847) 833-7010.
