Description
Automatic Speed, Manual Control — One Station
The Kresco GW500A combines a manual wash station with automated cleaning for shops doing frequent color or coating changes. Load a gun into the automatic station, keep painting, and come back to a clean gun — or use the manual station with air-powered gun, brush, and clean-rinse nozzle for detail work and cup adapters.
Key Features
- 2× automatic stations for gravity-feed spray guns
- 1× automatic station for suction-feed spray guns
- Full manual station — air-powered gun, manual brush, wash nozzle, clean-rinse nozzle
- Hybrid cleaning — solvent or water-based paint equipment
- Automatic fume extraction and lid safety interlock
- Galvanized steel frame, stainless steel reservoir
Specifications
| Feature | GW500A |
|---|---|
| Wash stations | 1 manual / 1 automatic |
| Capacity | 2 spray guns / 2 cups |
| Dimensions (H × W × D) | 60″ × 28″ × 15¾″ |
| Weight | 126 lbs |
| Air supply | 40–90 PSI, ¼″ NPT |
| Warranty | 2 years parts / 5 years pump |
Close the Loop on Your Cleaning Solvent
Pair the GW500A with a solvent recycler to distill dirty gun-wash solvent back to clean on site — less new solvent purchased, up to 90% less hazardous waste hauled away.
Request a quote for current pricing and lead time.
Which GW Series Washer Do You Need?
| Model | GW300M | GW500A | GW600T |
|---|---|---|---|
| Washing stations | 1 manual | 1 manual + 1 automatic | 2 manual + 2 automatic |
| Capacity | 1 gun / 1 cup | 2 guns / 2 cups | 2 guns / 2 cups per station |
| Automatic gravity-gun stations | — | 2 | 1 per station |
| Automatic suction-gun stations | — | 1 | 1 per station |
| Dimensions (H × W × D) | 60″ × 21″ × 15¾” | 60″ × 28″ × 15¾” | 60″ × 46″ × 15¾” |
| Weight | 104 lb | 126 lb | 154 lb |
| Air input | 40–90 PSI, 1/4″ NPT | ||
| Warranty | 2 years parts / 5 years pump | ||
| Best for | Medium-to-heavy single user, manual cleaning | One painter with frequent color changes | Two painters, or one solvent station and one waterborne station |
Powered by a Graco Air-Operated Double Diaphragm Pump
Every GW Series washer runs on a Graco air-operated double diaphragm pump: 5 US gallons per minute at 90 PSI on less than 2 CFM of air, so it won’t starve the paint booth’s air supply, and it carries its own 5-year warranty. Kresco’s Easy Locate universal spring support locks any gravity- or suction-fed gun in place for a complete wash and keeps fluid out of the gun’s air passages. The galvanized housing and stainless steel tank don’t corrode, and the built-in extraction fan starts the moment the lid opens; a lid-lock switch stops the cycle so nobody gets splashed.
Option: Inline Filtration
An optional inline filtration system with 10-micron cartridges traps paint residue from the circulating fluid. Cleaner fluid cleans better, the pump and nozzles last longer, you buy less cleaning solvent, and Kresco reports up to four times less hazardous waste leaving the shop.
Pair It With a Solvent Recycler
A gun washer turns clean solvent into dirty solvent every day. Put a Kresco SR30 or SR60 batch recycler next to it and that dirty solvent comes back at a 97% recovery rate in a 4–6 hour cycle, cutting pure-solvent purchases and eliminating about 90% of the waste you’d otherwise pay to haul. We sell the washer, the recycler, the recycling bags and the mineral spirits solvent, so one call covers the whole loop. Ask for a washer + recycler package quote or call (847) 833-7010.
