A Kresco Robotic Sandblast Cabinet puts a 6-axis robot arm inside an automated blast enclosure so the nozzle holds the ideal stand-off distance and angle on every square inch, every cycle. It is built for the highest standards in surface preparation and controlled shot peening, and for high-throughput production of repetitive parts where a human operator’s consistency is the limiting factor. Kresco integrates servo, CNC and robotic technology from leading automation partners, engineers each cell to the customer’s parts, and builds it in Quebec, Canada. Solvent Recycling Systems handles sales, project coordination and support in the US.
Start a robotic blasting project or call (847) 833-7010.
Why Put a Robot on the Nozzle
- Ideal stand-off distance and blasting angle, all the time
- Robots don’t tire and don’t miss a spot, so coverage and intensity are reproducible from first part to last
- Highest achievable quality and reliability for peening specs and cosmetic finishes
- Intuitive interface for data collection and sequence programming
- 3D modelling of parts for a precise surface treatment
- CAD/CAM integration with most design software
How It Works
The most common cell pairs a motorized turntable with a 6-axis robot blaster, the two moving in synchronization so the nozzle follows the part geometry at constant stand-off. Robots can also handle the parts rather than the nozzle, and a broad range of CNC and servo axes can be added to suit the process. Every system is tailored to the customer’s parts and specifications and designed to integrate with the surrounding production line.
Three Ways to Program a Blast Sequence
- Import a CAD file. The fastest path if you own the design: import it to the robot software and set process parameters such as stand-off and travel speed.
- 3D scan the part. When no CAD model exists, a scanner reproduces the part accurately enough to program from.
- Teach the robot. The longest route but sometimes the simplest: walk the robot through each movement manually.
Once a sequence is saved it runs with the same reproducibility every time it is recalled.
Typical Applications
Controlled shot peening of aerospace, medical and firearms components; cosmetic finishing of machined parts with a repeatable, specification-grade result; high-volume repetitive parts where a cabinet operator is the bottleneck. For simpler automation see the indexing turntable or rotary table blaster.
PLC Control With HMI Touch Screen
Critical operations are automated through a PLC with a touch-screen HMI: a main screen for everyday parameters, an alarm screen with current and resolved alarm history, a password-protected manual screen for maintenance staff, and an integrated maintenance program with reminders.
Media Recovery: Tunable Cyclonic Separator
Every Kresco automated system ships with a stand-alone cyclonic separator. Centrifugal force pulls dust, paint chips, rust and fines out of the air stream and returns sound abrasive to a storage hopper sized to your production target; an adjustable air inlet tunes it to angular or spherical media of any material, mesh size or bulk density, and a large debris drawer catches the rest.
| Separator | RB16 | RB24 | RB30 |
|---|---|---|---|
| Body diameter | 16″ | 24″ | 30″ |
| Air flow | 900 CFM | 1,200 CFM | 1,800 CFM |
| Inlet ID | 5″ / 6″ | 6″ / 7″ | 7″ / 8″ |
| Outlet ID | 7″ | 8″ | 8″ |
| Storage hopper | Custom to each order | ||
Cartridge Dust Collector
| Collector | CDC900 | CDC1200 | CDC1800 |
|---|---|---|---|
| Motor | 2 HP | 3 HP | 5 HP |
| Fan | 900 CFM | 1,200 CFM | 1,800 CFM |
| Filter cartridges / area | 2 / 636 sq ft | 4 / 1,272 sq ft | 4 / 1,272 sq ft |
| Overall (L × W × H) | 48″ × 23″ × 120″ | 48″ × 45″ × 124″ | 48″ × 45″ × 124″ |
| Shipping height | 90″ | 94″ | 94″ |
| Fan muffler | Under 80 dB | ||
Self-cleaning pulse system; adjustable legs assembled on site. More on the CDC cartridge collectors.
Other Kresco Automated Blasting Systems
- Rotary head table blaster — batches of flat parts on a motorized turntable
- Indexing turntable — four-station load/blast/blow-off/unload
- Basket blaster and rubber belt tumble blaster — bulk small parts
- In-line conveyor cabinet — continuous flow
- Cylinder and pipe blaster — 3/4″ to 60″ diameters
- Robotic sandblast cabinet — 6-axis precision and peening
Pricing and Lead Time
Automated systems are engineered to order around your parts, media and production rate. Send part drawings or photos with dimensions, parts per shift, the finish you need and your compressor’s CFM; we’ll return a configured proposal with lead time. Request a quote or call (847) 833-7010.
